项目Project

单位

VMC-1580

VMC-1690

BMC-1890

工作台面积Area of working table

mm

1700*800

1800*900

2000*900

X/Y/Z轴行程X/Y/Z axle travel

mm

1500/800/700

1600/900/680

1800/900/800

T型槽(数目-尺寸X间距)T-slot(number-dilmension X interval)

22mm*5个*135mm

22mm*5个*165mm

18mm*5个*165mm

主轴鼻端至工作台距离Distance between spindle nose and operating platform

mm

170-870

160-840

160*960

主轴中心至立柱距离Distance between spindle center to stand column

Mm

800

950

950

主轴转速Rotation speed of spindle

Rpm

8000

6000

6000

主轴锥孔Spindle taper

BT50

BT50

BT50

主轴电机功率Spindle motor power

HP

25(18.5KW)

25(18.5KW)

25(18.5KW)

三轴电机功率Triaxial motor power

KW

3.5

4.5

4.5

XYZ轴快速进给XYZ axis rapid feed

mm/min

15000*15000*12000

15000*15000*12000

15000*15000*12000

XYZ轴切削进给XYZ axis cutting feed

mm/min

1-5000

1-5000

1-5000

定位及重新定位精度Positioning and reposition accuracy

mm

±0.005/300mm/±0.003/300mm

工作台负荷Operating platform load

kg

1500

1600

1600

电力需求Power demand

kva

50

50

50

空压规格Air pressure specifications

kg/cm

6-7

6-7

6-7

机械重量Machine weight

kg

12000

13500

14000

外型尺寸(长*宽*高) Dimensions (L*W*H)

mm

4300*3200*3300

4450*3850*3500

4850*3300*3500
