项目Project

单位

L-650

L-680

L-1060

L-1270

工作台面积Area of working table

mm

800*500

1000*500

1200*600

1360*700

X/Y/Z轴行程X/Y/Z axle travel

mm

600/500/500

800/500/500

1000/600/600

1200/700/700

T型槽(数目-尺寸X间距)T-slot(number-dilmension X interval)

18mm*3个*14mm

18mm*5个*90mm

18mm*5个*100mm

18mm*5个*122mm

主轴鼻端至工作台距离Distance between spindle nose and operating platform

mm

110-610

110-610

150*750

150-750

主轴中心至立柱距离Distance between spindle center to stand column

Mm

560

560

600

785

主轴转速Rotation speed of spindle

Rpm

8000rpm/min(标记)10000-15000rpm/min(选配)

主轴锥孔Spindle taper

BT40

BT40

BT40

BT50

主轴电机功率Spindle motor power

HP

7.5(5.5KW)

10(7.5KW)

15(11KW)

20(15KW)

三轴电机功率Triaxial motor power

KW

X1.5/Y1.5/Z2

2

3

3

XYZ轴快速进给XYZ axis rapid feed

mm/min

30000*30000*18000

30000*30000*18000

30000*30000*18000

24000*24000*18000

XYZ轴切削进给XYZ axis cutting feed

mm/min

1-6000

1-6000

1-6000

1-6000

定位及重新定位精度Positioning and reposition accuracy

mm

±0.005/300mm/±0.003/300mm

工作台负荷Operating platform load

kg

550

650

800

1000

电力需求Power demand

kva

20

20

30

40

空压规格Air pressure specifications

kg/cm

6-7

6-7

6-7

6-7

机械重量Machine weight

kg

5000

6000

8000

9000

外型尺寸(长*宽*高) Dimensions (L*W*H)

mm

2280*2300*2400

2700*2300*2600

3290*2630*2700

3900*3100*3000
